Car carrier Centre axle trailer

“all types of car transportable” Carrying Specialist

Applicable to carry cars, SUV, MPV, Sports cars...etc.

Absolutely space advantage, loading 9 SUV 9 Audi a6, pass-ate...

Can load 9units Haval H6/ Ford KUGA /Audi A6, Passat at one time transportation. Also can loading 10 different types cars, realizing the multi model mixing loading, has the absolute loading advantage.

Semi trailer can operate individually from the prime mover, more easily to be used.

Designing a separated 4cars’ loading & discharging system upper body frame, which can be operated individually without connecting the truck head.

Reasonable structure, whole vehicle function is excellent, efficient, safety.

While absorbing the advantages of the good structure from the European, American cars, we fully considered about the Chinese road condition, clients driving habit... We take innovative design for it.

Loading 9unis Haval H6（L×W×H：4640×1825×1710）, total height at 4460-4500mm approximately.

Loading 9units Audi A6（L×W×H：4886×1810×1475），9units Passat（L×W×H：4872×1834×1484）total height at 4260-4300mm.The prime mover’s longitude go through semi trailer angled at 6.5°-7°.

The hydraulic system using the hydraulic lifting/downing cylinders, mechanic locks. Safety and reliable.

Using the hydraulic lifting/downing cylinders, mechanic locks, realizing the platforms of all cars’ elevating and positioning. Main hydraulic system ,controlling valves located at the prime mover, and its related devices controlled by the hydraulic system, and controlling valves all posited in the semitrailer part. Which is very easily, individually operated.

The good feasibility of this design, making multi kind of the chassis truck head/prime mover ca

The main car carrier trailer also adopts the modular style design, it can be easily and efficiently coupled with different prime movers. The connecting ways have 2 kinds:

Ball articulation connection and extendable connection saddle/fifth-wheel.

Environment protecting, and wisdom manufacturing.

This model is designed by the theory of modulars, high ......
