Telescopic Extendable Windmill Turbine Blade Trailer

BACK

Telescopic Extendable Windmill Turbine Blade Trailer

ELEPH Industry provides a specialized solution for hauling Windmill Turbine Blade. This versatile heavy haul Telescopic Extendable Trailer can be adjusted to fit any size or brand of Wind Turbine Blade with a shorter lighter design, making it the ideal option for hauling blades.

Detail

Loading Deck	14500mm-3500025001500mm
Rated Capacity	40-60Tons
Tare Weight	12-18Tons
Total Weight	52-78Tons
Wheelbase	1310mm
Axles	13T American Style	3/4 sets
Tyre	10.00R20;11.00R20;12R22.5	12/16sets
Rims	12/16pcs
Suspension	Air suspension with hydraulic steering & lifting functions, all accessories imported
Brake	Dual line pneumatic brake system,T30/30+T30 air chamber; parking brake;
Material	High Tensile Carbon Steel
Size	Upper plate	25mm
	Lower plate	25mm
	Mid Web	Box styled double 12mm
	Height	500-520mm
Floor	4mm diamond plate
Welding	automatic submerged arc welded
King pin	2’ or 3.5’ interchangeable
Landing Gear	28T with static 80Tons
Lights	Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
Painting	Three coats painting; Any color will be available
Tool Box	One tool box with a set of standard trailer tools
Tyre Carrier	One piece
Electrical	1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) Euro Standard
