Hydraulic Lifting PTA/Powder Tank Truck Trailer
Model	ALP9350PTAT
Dimension(Optional)	Axle No.	Rated Load (kg)		Tire No.	Tire Size
10000-30000liters/10-30cbm	2	40000		8	825R20 1000R20 1100R20 1200R20 12R22.5 (Other Size / Single Super Tire Contact with Supplier)
30000-60000liters/30-60cbm	3	60000		12
Above 60000liters/60cbm	4	75000		16
Manufacture	Qingdao Eleph Industry & Trade Co., Ltd
Wheel Base (mm)	1310
leaf-spring Pcs	10
Axle	13/16/18 T
Suspension	Heavy Duty Mechanic Suspension with Leaf Springs
Main Beam Material	Q345B manganese plates, automatic submerged arc welded
Brake System	Dual line braking system with automatic braking system/chambers
Brake Air Chamber	Double Model
Kingpin	2' or 3.5' Interchangeable
Landing gear	28T loading capacity with 80T static lifting capacity.
Tanker body	Sealing End		7.2mm , material: 5083(O)
	Tank Body		Aluminium 5.0/5083 H111、6.0/5083 H111
	Chassis		High Tensile Steel Q345A，Q550D
Brake System	Dual Lines Braking System With Automatic Air Chambers
Brake Air Chamber	Four double and two single chamber
Electrical System	24V, 7core socket, lights according to European standards.
Mainbeam Size	Upper plate		14mm
	Lower plate		16mm
	Mid Web		8 mm
	Height		500-520mm
Tool Box	1 box of standard tools
Spare tire carrier	2 sets
Color and Logo	Depends on the buyer’s requirement.
Pin Height	According to the height of the tractor saddle.
Painting	Three coats painting; Any color will be available
Manhole	2pcs
Body Material	Carbon Steel/ Stainless Steel/Aluminium
Ladders	Steel with anti slipper walking way
Lifting System	Hydraulic HYVA FC214-5-009030
	Maximum Lifting Angle: 46°
handrail	Steel, manual
Application	For Powder/ PTA / Aluminum Powder Transportation
