LPG TRANSPORT TANK TRUCK TRAILER
Model	ALP9350LTGT
Dimension(Optional)	Axle No.	Rated Load (kg)	Tire No.	Tire Size
10000-30000liters/10-30cbm	2	40000	8	825R20 1000R20 1100R20 1200R20 12R22.5 (Other Size / Single Super Tire Contact with Supplier)
30000-60000liters/30-60cbm	3	60000	12
Above 60000liters/60cbm	4	75000	16
Manufacture	Qingdao Eleph Industry & Trade Co., Ltd
Products	LPG, Butane , Propane
Fluid property	flammable
Design temperature	-40°C to 50°C
Design pressure	1.61MPa
Filling weight per volume	420Kg/m3
Maximum filling weight	24486Kg
Compartments	One
Baffle inside the tank	14-off bolted plate , 5mm
Shape	Cylindrical ; Ellipse head
Fire extinguisher	2 With red box
Flaw detection	100% Flaw detection
Hydrostatic test	2.1MPa
Manhole	1 ; On top
Safty Valve	1
Suspension system	Leaf spring 10pcs
Landing legs	28Ton
7-Pin Socket	24V 7-pin socket
LED Lamp	All kinds of lamp
Kingpin	90 and 50# Bolt-atble
Small Tool box	1
Wheel carrier	1
Corrosion allowance	1.0mm
Magnaflux	Aim at welding place flaw detection can not cover
Heat treatment	Overall heat treatment in a furnace , 500°C to 560°C
Major materials bearing pressure	Tanker body : Q345R , 12.5mm,End plate : Q345R , front：10mm，Rear:12.5mm ,Main Beam : T700
